If you’re a proud owner of a Toyota Camry or considering one, understanding the bolt pattern is crucial when upgrading or changing your rims. Let’s delve into the specifics of the Toyota Camry lug pattern, discussing what it means and what you need to consider when selecting new rims.

What Is The Toyota Camry Wheel Bolt Pattern?

The Toyota Camry typically has a bolt pattern of 5×4.5 in or 5×114.3 mm, commonly referred to as a “5-lug” pattern. The “5” signifies the number of bolt holes, while the “114.3” indicates the diameter in millimeters between adjacent bolt holes.

5 x 4.5″ bolt pattern

This bolt pattern is widely used across many Toyota models, as well as other popular car brands. It’s essential to know this trait because it ensures that the wheels you choose will fit perfectly and securely.

Other Wheel Specs Of Toyota Camry

In addition to the bolt pattern, there are several other important wheel specifications to consider when it comes to the Toyota Camry.

  • Center bore diameter: a significant factor in wheel fitment, determines the size of the hole in the center of the wheel, ensuring a precise fit onto the vehicle’s hub. The Toyota Camry’s center bore is 60.1 mm.
  • Wheel tightening torque: specifies the amount of force required to properly secure the wheels on the hub, maintaining stability and safety. The torque spec of Toyota Camry is normally 103 Nm.
  • Thread size: refers to the dimensions of the wheel lug bolts or nuts, ensuring compatibility with the corresponding wheel studs. This spec in Toyota Camry is M12 x 1.5.
  • Wheel offset: This element plays a significant role in wheel fitment, referring to the distance between the wheel’s mounting surface and the centerline. It affects the wheel position within the wheel well and can impact handling and clearance. The Toyota Camry typically has a rim offset in the range of +36mm to +45mm.

How To Measure Toyota Camry Lug Pattern

Measuring the lug pattern of your Toyota Camry is a straightforward process. You can use my personal step-by-step method to measure the lug pattern accurately.

Step 1: Park your Toyota Camry on a flat, level surface and engage the parking brake to ensure stability.

Step 2: Locate one of the wheels on your Camry and remove the hubcap or center cap if applicable, exposing the lug nuts.

Step 3: Count the number of lug nuts on the wheel. Note that the lug pattern is denoted by the number of lug nuts present. Typically, the Camry has five lug nuts, resulting in a 5-lug design.

Step 4: Measure the distance between adjacent lug nut holes. Stretch the ruler of the tape measure from the back of one lug nut hole to the opposite one’s center. This measurement represents the bolt circle diameter.

Measure lug pattern

Step 5: Write down the measurement in millimeters. It’s crucial to record the wheel size accurately for future reference.

Step 6: Repeat the process for another wheel on your Camry to ensure consistency and verify your measurement.

Frequently Asked Questions

Are 5×114.3 To 5×100 The Same?

No. The numbers indicate the spacing and arrangement of the bolts on the wheel hub. A bolt pattern of 5×114.3 means that there are 5 bolts spaced 114.3 millimeters apart. Meanwhile, 5×100 shows there are 5 bolts spaced 100 millimeters apart. These bolt patterns are not interchangeable without using adapters or modifications.

What Is The Bolt Pattern On A 2009 Toyota Camry?

The current bolt pattern on a 2009 Toyota Camry is 5×114.3. This refers to the arrangement and spacing of the bolts on the wheel hub. The “5” indicates that there are five lug holes on the hub, while “114.3” represents the diameter of the bolt circle in millimeters.

What Rims Will Fit A 2009 Toyota Camry?

It is recommended to choose rims that have a bolt pattern of 5×114.3. Also, the most recent Toyota Camry models come standard with many tire sizes, including 17-inch, 18-inch, and 19-inch rims.

The Bottom Line

In conclusion, being familiar with the bolt pattern for Toyota Camry is essential for any owner looking to enhance the style or optimal performance of their vehicle through rim upgrades. With the right rims, you can give your Camry a personalized touch that matches your style and preferences.
